2 Dimmable Load 4 Normal Load 6A And Socket Load 6A Wifi Touch Switch

2 Dimmable Load 4 Normal Load 6A And Socket Load 6A Wifi Touch Switch Specification

Power Factor
>0.95

Operating Temperature
-10C to 60C

IP Rating
IP44

Overheating Protection
YES

Feature
WiFi Enabled, Touch Operated, Dimmable Support, Remote Access

Shape
Rectangular

Humidity %
95% RH

Efficiency
>95%

Surface Finish
Glossy

Connector Type
Screw Terminal

Mounting Type
Wall Mount

Insulation Material
High-grade Plastic

Product Type
Touch Switch

Application
Electric Fitting

Protection Level
Surge Protection, Overload Protection

Frequency (MHz)
50 Hertz (HZ)

Rated Voltage
220-240V AC

Energy Consumption
Low

Output Type
2 Dimmable Load, 4 Normal Load, 1 Socket Load

Color
Black

Dimension (L*W*H)
86mm x 86mm x 38mm

Weight
120g

Warranty
Yes

Size
Standard Switch Size

Phase
Single Phase

Input Voltage
220-240V AC

No Of Poles
2

Connection Type
Wire Terminal

Material
Flame Retardant Polycarbonate

WiFi Standard
2.4 GHz

Response Time
<20ms

Maximum Load Socket
6A

Cutout Size
75mm x 75mm

Panel Type
Capacitive Touch

Maximum Load Dimmable Circuit
6A

Maximum Load Normal Circuit
6A

Standby Power Consumption
<0.5W

LED Indicator
Blue (On), Red (Off)

Wireless Range
Up to 30 meters (open area)

Rated Current per Channel
6A max

Power Supply
Neutral and Live required

Voice Control Support
Amazon Alexa, Google Assistant

Switch Life Cycle
>100,000 cycles

App Compatibility
Android, iOS (Smart Life, Tuya compatible)

2 Dimmable Load 4 Normal Load 6A And Socket Load 6A Wifi Touch Switch Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About 2 Dimmable Load 4 Normal Load 6A And Socket Load 6A Wifi Touch Switch

Discover the elite 2 Dimmable Load 4 Normal Load 6A and Socket Load 6A WiFi Touch Switch-engineered for India's discerning buyers at the best price. Enjoy stellar efficiency with dimmable and normal load management, topped by advanced surge and overload protection for noble safety. Compatible with Amazon Alexa, Google Assistant, and supported by Smart Life and Tuya apps, this glossy, flame-retardant device crowns your electric fittings with seamless touch, remote, and voice control. It's a truly noble deal for smart, reliable convenience.

Elite Applications with Leading-Edge Features

This WiFi-enabled touch switch excels on widely-used wall surfaces owing to its sleek, rectangular design and flame-retardant polycarbonate build. With dual dimmable loads and dedicated socket control, adjust lighting and devices seamlessly using capacitive touch or remotely. Capable of integrating with Android, iOS, Amazon Alexa, and Google Assistant, it simplifies electric fitting management for both home and office environments-delivering smart automation and reliable connectivity with stellar flexibility.

Certifications, Delivery, and Global Market Value

Benefit from a WiFi Switch designed to meet the highest standards-protected by IP44 and incorporating overheat, surge, and overload safeguards. Backed by a trusted warranty and manufactured to global norms, fast delivery is assured across dealer, distributor, and supplier networks. Its competitive sale price positions it with excellent market value, making this advanced device a highly sought-after export, especially by wholesalers and buyers from international markets seeking top-quality at a modest asking price.

FAQ's of 2 Dimmable Load 4 Normal Load 6A And Socket Load 6A Wifi Touch Switch:

Q: How does the WiFi Touch Switch support remote and voice control?

A: The device integrates seamlessly with Smart Life and Tuya apps for remote operation via Android and iOS. It also supports voice commands through Amazon Alexa and Google Assistant, enabling hands-free control of dimmable, normal, and socket loads.

Q: What makes the touch switch's application surface durable and reliable?

A: Constructed from high-grade, flame-retardant polycarbonate, the touch switch offers a robust, glossy panel that endures high usage, with a rated switch life exceeding 100,000 cycles and protection against overheating, surges, and overloads.

Q: Where can this WiFi Touch Switch be installed?

A: Designed for standard switch cutouts (75mm x 75mm), this switch fits most wall-mounted installations in homes, offices, and commercial spaces, offering elite electrical functionality in new or retrofit electric fittings.

Q: What is the process of setting up the smart switch?

A: Simply mount the switch in the wall, connect neutral and live wires via screw terminals, and configure the device through your WiFi (2.4 GHz). Then, link it to your preferred app for quick setup and customizations.

Q: What are the main advantages of using this WiFi-enabled switch?

A: Key benefits include efficient dimming, responsive touch (under 20ms), overload and surge protection, low standby energy consumption, reliable remote management, and modern voice-integrated control for optimal user comfort and safety.

Q: When is this product typically delivered after purchase?

A: Dealers and suppliers strive for prompt shipment post-sale; actual delivery time depends on your location and shipping method, but most orders are dispatched quickly for minimal waiting time.
